InAsSb Amplified Photodetector

Overview
IdealPhotonics' InAsSb indium arsenide antimony amplification detector is an tunable detector covering the 3-12μm mid-to-long-wave infrared range by adjusting the arsenide and antimony composition. Some models support thermoelectric cooling (-40°C) operation, balancing performance and power consumption. Its applications include industrial thermal imaging and fire early warning systems.High detectivity (>10¹⁰ Jones) in the 8-14μm atmospheric window, with some models requiring no cooling, presents a potential alternative to HgCdTe.

Claire Lee

Phone:+86 13032176908

Email:claire@idealphotonics.com

WeChat:

2-12um cadmium telluride mercury amplifying photodetector - adjustable gain

IdealPhotonics’MCT amplification photodetector has a photosensitive range covering 2-12um, with 8 adjustable gain levels, capable of quantitative photoelectric conversion, wide dynamic range, suitable for various infrared photoelectric development scenarios, excellent performance, high cost-effectiveness, and provides Quan directional technical support. It is commonly used in mid to long wave infrared measurement.

Product InformationModel Wavelength RangeSensitive Area SizePhotoelectric Response Operate

2-12μm MCT Amplified Photodetector, Sensitive Versio MP-CPD-M-M-A-A-R10-S 2-12um1mm×1mm≥0.14A/W Add to Cart

2-12μm MCT Amplified Photodetector MP-CPD-M-M-A-A-R10 2-12um1mm×1mm≥0.004A/W Add to Cart

0 Selected Items Add to Cart
