MM Fiber

Overview
IdealPhotonics' multimode fiber is a type of fiber with a relatively large core diameter (typically 50/62.5μm), allowing multiple optical transmission modes to pass simultaneously. Its core feature is achieving high-capacity signal transmission over low-cost, short-distance distances (such as 100-meter-level LANs), but its bandwidth is limited by modal dispersion."Large-core diameter (50/62.5μm) multimode transmission" achieves high-capacity signal transmission over low-cost, short-distance (100-meter-level) distances, but its bandwidth is limited by modal dispersion. Typical applications include high-speed, short-distance scenarios such as data centers and LANs.

Claire Lee

Phone：+86 13032176908

Email：claire@idealphotonics.com

WeChat：

Communication multimode fiber (62.5/125um)

Product InformationModel Core DiameterCladding DiameterCoating Diameter Operate

Communication multimode optical fiber (62.5/125um) IP-MMF-62.5/125 62.5±2.5um125.0±1.0245±7 Add to Cart

0 Selected Items Add to Cart

Mid infrared ZBLAN fluoride core energy transmission fiber with a wavelength of 0.3-5um

ZBLAN fiber is a composite glass fiber composed of heavy metal fluorides such as ZrF4, BaF2, LaF3, AlF3, and NaF. Compared with widely used quartz optical fibers, ZBLAN optical fibers have the characteristics of a wide transmission wavelength range (0.35 μ m~4 μ m) and high emission efficiency of doped rare earth ions. By developing a unique fiber manufacturing technology, Idealphotonics has introduced low-cost production of high-quality (especially low loss) fluoride fibers.

Product InformationModel Core diameter numerical aperture Operate

ZBLAN Mid-Infrared Large Core Power Transmission Fiber, Core Diameter 400μm MP-ZMF-400/500-27-DE 400±25µm0.27 Add to Cart

ZBLAN Mid-Infrared Large Core Power Transmission Fiber, Core Diameter 100μm MP-ZMF-100/125-27-DE 95±5µm0.27 Add to Cart

ZBLAN Mid-Infrared Large Core Power Transmission Fiber, Core Diameter 160μm MP-ZMF-160/200-27-DE 160±5µm0.27 Add to Cart

0 Selected Items Add to Cart

Large core energy transmission fiber (core diameter 100-900um)

We are currently able to provide international commercial grade quartz energy fibers in bulk. Our energy fibers include two categories: quartz clad high-performance energy fibers and plastic clad performance energy fibers. Quartz clad energy fiber can transmit high laser power, has good resistance to optical damage, as well as low attenuation and high light transmittance (from 400nm to 1600nm in the near ultraviolet to near infrared bands)

Product InformationModel Core DiameterClad DiameterCoating Diameter Operate

100um large core energy transmission optical fiber MP-PDF-100/140 100um140um245um Add to Cart

105um large core energy transmission optical fiber MP-PDF-105/125 105um125um245um Add to Cart

200um large core energy transmission optical fiber MP-PDF-200/230 200um230um380um Add to Cart

400um large core energy transmission optical fiber MP-PDF-400/440 400um440um535um Add to Cart

600um large core energy transmission optical fiber MP-EDF-600/660 600um660um850um Add to Cart

900um large core energy transmission optical fiber MP-EDF-900/990 900um990um1370um Add to Cart

Show All

0 Selected Items Add to Cart
