800–890nm OCT Spectrometer

The 800-890nm OCT spectrometer is a high-performance spectral acquisition module designed for spectral-domain optical coherence tomography applications. Covering a wavelength range of 800-890 nm, the product employs a high-efficiency transmission grating and an optimized optical architecture, combined with a high-speed 2048-pixel linear array detector, to deliver high spectral resolution, high optical throughput, and fast spectral acquisition. In OCT applications, this spectrometer enables a typical axial resolution of 4.1μm in air and a maximum measurement depth of 4.0 mm (in air), making it suitable for SD-OCT systems in ophthalmology, biomedical imaging, research, and industrial nondestructive testing.
