Threshold Current

Ith

-

-

-

180

mA

Center Wavelength

λC

at rating output power, RMS (-20dB)

λC−1.0

λC

λC+1.0

nm

Spectral Width

Δλ

at rating output power, -10dB

-

-

3.5

nm

PD Monitor Current

Im

at rating output power, VRD=5V

100

-

2000

μA

PD Dark Current

Id

VRD=5V

-

-

0.1

μA

Tracking Error

ΔPf

Im=const., TC=−20 to 70∘C

-0.5

-

0.5

dB

Thermistor

Rth

TLD=25∘C, B=3900±100K

9.5

10

10.5

kΩ

Polarization Extinction Ratio

Xp

at rating output power

17

-

-

dB

LD Forward Current

IF

2200

mA

LD Reverse Voltage

VR

2

V

PD Forward Current

IFD

10

mA

PD Reverse Voltage

VRD

20

V

Case Operating Temperature

TC

-20 to +70

°C

Storage Temperature

Tstg.

-40 to +85

°C

Cooler Current

IC

5.8

A

BOL [V]

EOL [V]

1420 to 1499 nm

300

1150

2.0

2.3

2.20

2.70

320

1200

2.0

2.3

2.20

2.70

340

1300

2.0

2.3

2.30

2.80

350

1400

2.0

2.3

2.35

2.85

360

1400

2.0

2.3

2.40

2.90

380

1400

2.0

2.3

2.45

2.95

400

1400

2.0

2.3

2.50

3.00

1420 to 1485 nm

420

1600

2.2

2.5

2.60

3.10

450

1700

2.2

2.5

2.70

3.20

500

1800

2.2

2.5

2.90

3.40

Cutoff Wavelength

1300

-

1400

nm

Mode Field Diameter (MFD) @1550nm

10.0

10.5

11.0

μm

Cladding Diameter

124

125

126

μm

UV Coating Diameter

230

245

260

μm

FBG Wavelength Temperature Coefficient

-

0.01

0.02

nm/°C

Bend Radius

30

-

-

mm
