Output Power

Up to 200mW

Up to 2000mW

Up to 1500mW

Up to 200mW

Wavelength

320 nm

349 nm

532 nm

640 nm

780 nm

Spectral Width

≤ 0.5 MHz

≤ 0.3 MHz

Spatial Mode

TEM00

Spectral Stability

± 0.2 pm (over 8 hours operation)

Coherence Length

> 100 m

Output Power Stability

≤ 2.0 % (over 8 hours operation)

≤ 1.0 % (over 8 hours operation)

≤ 2.0 % (over 8 hours operation)

Output Power Noise

≤ 0.1 % RMS (10 Hz – 10 MHz)

Beam Divergence

1.0 mrad, diffraction-limited

Beam Pointing Stability

0.6 - 1.2 mm

0.7 - 1.1 mm

0.8 - 1.2 mm

Beam Pointing Stability

≤ 5 μrad/°C

Laser Head Dimensions

240 x 150 x 100 mm

210 x 100 x 80 mm

180 x 100 x 80 mm

L x W x H

Beam Height

65 mm

Environmental Conditions, Ambient Temperature Range

18 - 30 °C

Laser Head Interface Stability

± 1.5 °C

Storage Temperature

0 - 50 °C

Humidity

0 - 50 %, non-condensing
