Center wavelength

λ

2326

2327

2328

nm

Side Mode Suppression Ratio

SMSR

30

40

dB

Threshold current

Ith

20

30

mA

Operating current

Iop

80

120

mA

Fiber output power

Pf

4

5

10

mW

Quantum Efficiency

η

0.08

0.12

mW/mA

Current Tuning Coefficient

∆λ/∆I

0.015

nm/mA

Temperature Tuning Coefficient

∆λ/∆T

0.12

nm/K

Forward Voltage

Vf

1.3

2

V

Thermistor resistance value

RT

9.5

10

10.5

KΩ

Thermistor temperature coefficient

-4.4

%/℃

connectors

FC/APC

1

TEC (+)

8

N/C

2

Thermistor

9

Laser Cathode (-)

3

Monitor Detector Anode (-)

10

Laser Anode (+)

4

Monitor Detector Anode (+)

11

N/C

5

Thermistor

12

N/C

6

N/C

13

Case Ground

7

N/C

14

TEC (-)

Shell temperature

℃

-5

25

70

Chip temperature

℃

+10

25

40

Operating current

mA

0

100

150

Forward voltage

V

0.8

1.2

1.8

Semiconductor Refrigerator (TEC) Current

A

-

-

1.2

Laser diode (LD) reverse voltage

V

-

-

2.0

Photodiode (PD) reverse voltage

V

-

-

20
