Center wavelength

λ

1909

1910

1911

nm

Side Mode Suppression Ratio

SMSR

30

40

dB

Threshold current

Ith

20

30

mA

Operating current

Iop

80

120

mA

Fiber output power

Pf

2

3

5

mW

Quantum Efficiency

η

0.08

0.12

mW/mA

Current Tuning Coefficient

∆λ/∆I

0.015

nm/mA

Temperature Tuning Coefficient

∆λ/∆T

0.12

nm/K

Forward Voltage

Vf

1.3

2

V

Thermistor resistance value

RT

9.5

10

10.5

KΩ

Thermistor temperature coefficient

-4.4

%/℃

connectors

FC/APC

1

Thermistor

8

Case Ground

2

Thermistor

9

Case Ground

3

Laser Cathode (-)

10

N/C

4

N/C

11

Laser Anode (+)

5

N/C

12

Laser Cathode (-)

6

TEC (+)

13

Laser Anode (+)

7

TEC (-)

14

N/C

Shell temperature

℃

-5

25

70

Chip temperature

℃

+10

25

40

Operating current

mA

0

100

150

Forward voltage

V

0.8

1.2

1.8

Semiconductor Refrigerator (TEC) Current

A

-

-

1.2

Laser diode (LD) reverse voltage

V

-

-

2.0

Photodiode (PD) reverse voltage

V

-

-

20
