Metallized single-mode gold-plated optical fiber (high temperature resistant optical fiber)

copper-aluminum coated and gold coated single-mode fiber for near-infrared wavelength range is usually in stock. Orders over 20m in length can be shipped the same day. Custom single-mode configurations (including pure silica core or custom wavelength) may require a minimum order quantity of 1 km and a lead time of 6 weeks Refer to SM9-125-IRMG155 Customized model.

Product features：High temperature resistance、 Durability, high bending strength and sealing、 Possibility of embedding optical fiber, optical fiber bundle and pigtail into high vacuum environment for welding

Application area：High temperature environment、 Harsh chemical environment、 Nuclear radiation environment、 High power laser transmission、 Medical application、 Optical fiber bundle welding

Unit Price

Please contact customer service for a discounted quote.

Part Number

Au9/125-SMF

Lead Time

Please contact customer service for lead time.

Stock

Please contact customer service for stock availability.

Add to Inquiry

Inquire online

General Parameters

Download Document

Dimensional Drawing

Parameter

parameter	Indication
Core material	Ge-dop. SiO2
Numerical aperture	0.12 +/- 0.02
Mode field diameter	9.2 +/- 0.4µm@1310nm ；10.4 +/- 0.5µm@1550nm
Cut-off wavelength	1200 - 1330nm
Cladding diameter	125 +/- 2µm
Coating diameter	155 +/- 16µm
Coating material	Gold
Verification test	100 kpsi
Operating temperature	-269°C to 700°C
